Teltonika TSW212: Industrial Managed Network Switch with 8 Gigabit Ethernet Ports and 2 SFP Ports
- Stock: In Stock
- Brand: Teltonika Networks
- Model: TSW212
- Weight: 615.00g
- Dimensions: 122.00cm x 132.00cm x 44.20cm
- MPN: TSW212
Are you looking for a reliable, versatile, and powerful switch that can handle any network challenge? Do you want to optimize your network performance and security with advanced features and protocols? Do you need a switch that can withstand harsh industrial environments and provide long-range connectivity?
If you answered yes to any of these questions, then you need the Teltonika TSW212. This is the industrial-grade switch that supports multiple protocols and fibre optic communication. It is designed for network professionals who demand the best from their network devices.
Key Features
The Teltonika TSW212 is an L2-managed switch with additional L3 features. It offers the following features:
- 8 Gigabit Ethernet ports and 2 SFP ports for Fibre optic communication. This ensures robust long-range connectivity and high-speed data transmission. You can connect your network devices with different media types and distances, without compromising on performance or reliability.
- Profinet, EtherNet/IP, and MRP support. These protocols enable seamless integration with various industrial devices and systems, such as PLCs, sensors, actuators, and robots. You can monitor and control your network devices with ease and accuracy.
- Static IPv4 and IPv6 routing, DHCPv6 client, and port settings. These features provide advanced network management capabilities, allowing you to configure your network according to your needs and preferences.
- Loop protection, VLAN, STP/RSTP, QoS, and port mirroring. These features enhance the security and efficiency of your network, preventing loops, isolating traffic, prioritizing packets, and monitoring ports.
Other Features You’ll Love
This particular Managed Network Switch stands out from other products on the market because of its unique selling points, such as:
- Rugged Anodized Aluminum Housing: Encased in anodized aluminum housing that can withstand extreme temperatures and resist severe vibrations. It is designed for harsh industrial environments where other switches would fail.
- Smart Web GUI: It has a user-friendly web interface that allows you to easily configure and manage your network device’s settings. You can access the web GUI from any device with a web browser, such as a laptop or a smartphone.
- Remote Management: The Teltonika TSW212 supports remote management via RMS, SNMP, or Telnet protocols. You can monitor and control your device from anywhere in the world using a centralized management system.
Don’t Just Take Our Word For It
See what our customers have to say about this network switch:
“We use the Teltonika TSW212 in our factory to connect our PLCs and robots. It works flawlessly with the Profinet protocol and provides high-speed data transmission. We are very satisfied with its performance and reliability.” - John S, Factory Manager
“The Teltonika TSW212 is a great switch for our power plant. It supports fibre optic communication over long distances and has advanced security features. It also has a rugged design that can handle high temperatures and vibrations.” - Lisa J., Power Plant Engineer
“We have installed the Teltonika TSW212 in our train station to connect our CCTV cameras and ticket machines. It supports EtherNet/IP protocol and has a user-friendly web interface. It also has a low power consumption and a compact size.” - Mark L., Train Station Operator
Technical Specifications
Get geeky with the full TSW212 technical specifications below.
| FEATURES | |
|---|---|
| LAN | Multi-layer managed 8 x LAN ports, 10/100/1000 Mbps supports auto MDI/MDIX crossover |
| Fibre | 2 x SFP ports |
| IEEE 802.3 series standards | IEEE 802.1p, IEEE 802.1Q, 802.3az |
| SERVICES | |
| EtherNet/IP | Yes |
| Profinet (class B) | Yes |
| SNMP V2, V3 | Yes |
| LLDP | Yes |
| NETWORK | |
| MRP | MRP client role, MRP manager role |
| L2 Features | Loop protection, Forwarding table, VLAN, STP/RSTP |
| DHCP | DHCP Server, DHCP client |
| Port Settings | Enable/Disable, Link Speed Control, Port Isolation, EEE (802.3az) management, Port Mirroring |
| L3 Features | Static IPv4 Routing, Static IPv6 Routing, DHCPv6 client, Static IPv6 address |
| QoS | |
| QoS | Port priority, DSCP priority, 802.1p priority, TOS |
| Scheduling Method | SP/WFQ/WRR |
| Bandwidth Control | Rate limiting, storm control |
| DIAGNOSTICS | |
| Tools | Cable diagnostic, ping, traceroute, nslookup |
| PERFORMANCE SPECIFICATIONS | |
| Bandwidth (Non-blocking) | 20 Gbps |
| Packet Buffer | 512 KB |
| MAC address table size | 8K entries |
| Jumbo Frame Support | 10000 bytes |
| SYSTEM CHARACTERISTICS | |
| RAM | 128MB, DDR3 |
| FLASH storage | 16MB serial flash |
| FIRMWARE / CONFIGURATION | |
| WEB UI | Update FW from a file, check FW on the server, configuration profiles, configuration backup |
| FOTA | Update FW |
| RMS | With Teltonika RMS, you are enabled to update Firmwware, and configuration for multiple devices at once |
| Keep settings | Update FW without losing the current configuration |
| FIRMWARE CUSTOMISATION | |
| Operating system | TSWOS (OpenWrt-based Linux OS) |
| Supported languages | BusyBox Shell, Lua, C, C++, and Python, Java in Package Manager |
| Development tools | SDK package with build environment provided |
| POWER | |
| Connector | 2-pin industrial DC power socket |
| Input voltage range | 7 - 57 VDC |
| Power consumption | Idle: < 2.5 W / Max: 6 W |
| PHYSICAL INTERFACES | |
| Ethernet | 8 x RJ45 ports, 10/100/1000 Mbps |
| Fibre | 2 x SFP ports |
| Status LEDs | 1 x Power LED, 1 x Aux LED, 16 x LAN status LEDs, 2 x SFP status LEDs |
| Power | 1 x 2-pin industrial DC power socket |
| Reset | Software Reset Button |
| Grounding | Grounding Screw |
| PHYSICAL SPECIFICATION | |
| Casing Material | Anodized aluminum housing and panels |
| Dimensions (W x H x D) | 132 x 44.2 x 122 mm |
| Weight | 615 g |
| Mounting Options | Integrated DIN rail bracket, wall mounting (additional kit needed), flat surface placement |
| OPERATING ENVIRONMENT | |
| Operating Temperature | -40 °C to 75 °C |
| Operating Humidity | 10 % to 90 % non-condensing |
| Ingress Protection Rating | IP30 |
| REGULATORY AND TYPE APPROVALS | |
| Regulatory | CE, CB, RCM, FCC, IC, EAC, UCRF |
| EMC EMISSIONS & IMMUNITY | |
| Standards | EN 55032:2015+A1:2020; EN 55035:2017+A11:2020; EN IEC 61000-6-2:2019 |
| ESD | EN 61000-4-2:2009 |
| Radiated Immunity | EN IEC 61000-4-3:2020 |
| EFT | EN 61000-4-4:2012 |
| Surge Immunity (AC Mains Power Port) | EN 61000-4-5:2014+A1:2017 |
| CS | EN 61000-4-6:2014 |
| DIP | EN IEC 61000-4-11:2020 |
| SAFETY | |
| Standards | IEC 62368-1:2018 |
Downloads
- Download Tech Spec (PDF)
How & Where to Buy?
What are you waiting for? Order today!
The Teltonika TSW212 is the smart switch for a smarter world. Boost your network performance and reliability. You won’t regret it.
To order the Teltonika TSW212 Industrial Managed Network Switch, you can drop by our store (needs prior appointment) located at Novatel Communications, 12 Main Street, Buttevant, Co. Cork, Ireland.
To purchase online, simply click on the Add to Cart button, and then go through the fast, easy, and secure checkout process. Payment is provided for your convenience via Stripe or AIB Payment Gateway. You can use any card supported by them (MasterCard, Visa, American Express, Diners, and more…).
How Will My Order Be Delivered?
Your order(s) will be shipped via express delivery and are normally delivered within 1-4 business days. Your order will be dispatched directly from our warehouse and you will be provided a piece of tracking information for your order after it is dispatched. If you have any questions on your order status, please contact us.
You can check out the TSW202 if you need a PoE+ capable managed network switch. Model TSW101 is also available for purchase.
