Poynting XPOL-2-5G: 11dBi WiFi/4G/5G Cross Polarised MIMO Outdoor Antenna - Main

Poynting XPOL-2-5G: 11dBi WiFi/4G/5G Cross Polarised MIMO Outdoor Antenna - Main
€219.00
Ex Tax: €178.05
  • Stock: In Stock
  • Brand: Poynting
  • Model: XPOL-2-V3-5G
  • Weight: 1.98kg
  • Dimensions: 37.50cm x 26.70cm x 9.80cm
  • EAN: 6009880915750
  • MPN: A-XPOL-0002-V3

Available Options

It works on Wi-Fi and cellular frequency bands. It is Poynting’s third generation breed of the well-known cross-polarised MIMO antenna - the XPOL-2-5G (some folks misspell the model number as xpol2)

Use this incredibly uncomplicated to install unidirectional outdoor panel antenna to transmit & receive WiFi, or passively boost 4G, and 5G signal reception without interruption or delay. It is suitable for houses in urban as well as rural areas. You can use it to get high internet speeds even in factories and industrial settings. Its advanced metamaterial technology makes it capable of providing exceptional performance over the main 4G/5G bands and a very high gain for its size.

Quick Features

You can read the full technical data sheet on this section.

  • 2-3db Higher Gain
  • Lightweight & Rugged
  • Wall or Pole-mountable
  • Weatherproof & Waterproof (IP65)
  • Consistent Broadband Performance
  • New 3400mhz-3800mhz 3400 - 4200 MHz, 5G Bandwidth 11dbi Gain
  • High-pattern Consistency Across Bands For 4G/5G Carrier Aggregation
  • 2 Cross-Polarised Antennas in One Enclosure For Optimal Performance
Image: XPOL-2-V3-5G Features
XPOL-2-V3-5G Features

Use Cases & Applications

  • Municipal & Government Systems
  • Oil & Gas Communication Systems
  • Consumer LTE/5G Internet Connectivity
  • Power, Energy & Water Telemetry Access
  • Industrial & Commercial LTE/5G deployments
  • Repeaters & Coverage Enhancement Amplifiers
  • Agricultural & Farming LTE/5G data distribution
  • Outdoor antenna for Fixed Wireless Access (FWA)
  • Urban & Rural Household Signal Reception Enhancement

Sample Application

This cellular antenna unit is easy to install, and compatible with various routers and modems.

One of the compatible routers is the Teltonika RUTX50, a Dual SIM Card, multi-network router that offers 5G mobile communication for high-speed and data-heavy applications. It has 5 Gigabit Ethernet ports (1 WAN GigE / 4 LAN GigE), dual-band Wi-Fi, and supports both standalone (SA) and non-standalone (NSA) 5G architectures. It also has backward compatibility with 4G and 3G networks, and multiple interfaces for future expansion.

To configure a 4x4 MIMO for a 5G connection, you will need two units of the XPOL-2-5G antenna and one unit of the RUTX50 router. The 4x4 MIMO configuration will allow you to use four independent data streams on the same frequency band, increasing the data throughput and signal quality.

NOTE: The RUTX50 is capable of Multiple WAN or Internet Bonding via Bondix S.A.NE software . WAN bonding is a way of merging multiple Internet connections into one. It aims to boost network speed, stability, and backup.

Why XPOL-2-5G?

Essentially, these are the reasons why you would want to own this remarkable cellular antenna.

More MBs Per Second

With an 11 dBi gain across all kinds of outdoor and indoor environments, it can support higher internet speeds and provide you with a seamless and fast internet connection.

4G LTE and 5G Supported

It includes two cross-polarised antennas in a single enclosure to make sure that you can enjoy optimal LTE and 5G performance at your location.

Weather, Dust, and Vandal-resistant Enclosure

It can stand harsh weather conditions and is suitable for use both outdoors and indoors. With its IP65 certification for safety from weather, dust, and vandalism, it can definitely provide uninterrupted signals under all circumstances.

Heat and Cold Resistance

Poynting XPOL-2-V3-5G can stand temperatures as low as -40 degrees Celsius and as high as +80 degrees Celsius. It is perfect for all climates.

Wind Survival

The antennae can survive winds speeds up to 250 km/hour. With the Z-bracket included, it can survive wind speeds up to 160 km/hour. With an optional bracket BRKT-030, you can increase its bracket’s wind survival to 250 km/hour as well.

Waterproof

Thunderstorms and torrential rain will never cause any problems with your internet – this unidirectional antenna can handle exposure to water as well.

Technical Specification

Below table is the full technical specifications of the XPOL-2-V3-5G antenna, also known as XPOL-2-5G.

Electrical Specifications - Cellular
Frequency Bands 698-960 MHz
1710-2700 MHz
3400-3800 MHz
3400 - 4200 MHz
Gain (max) Port 1 & 2 11 dBi
VSWR Port 1 & 2 ≤1.5.1
over 95% of the band
Feed Power Handling 20W
Input Impedance 50 Ohm (nominal)
Polarisation ±45°
Coax Cable Loss 0.35 dB/m @ 900 MHz
0.53 dB/m @ 2000 MHz
0.6 dB/m @ 2500 MHz
0.66dB/m @ 3500 MHz
DC Short Path to ground
Mechanical Specifications
Product Dimensions 255mm x 255 mm x 80 mm
Packaged Dimensions 290 mm x 276mm x 98mm
Weight 1.55 kg
Packaged Weight 1.98 kg
Radome Material UV Stable SAN Marine ASA
Radome Colour Brilliant White
Pantone P 179-1 C
Mounting Type Wall and pole mount
Environmental Specifications, Certification & Approvals
Wind Survival Antenna wind survival: <250 km/h
Included Z-Bracket wind survival: <160km/h
Optional bracket BRKT-030* is required for wind speeds of <250 km/h
Temperature Range (Operating) -40°C to +80°C
Environmental Conditions Outdoor/Indoor
Water ingress protection ratio/standard IP65
Salt Spray MIL-STD 810F / ASTM B117
Operating Relative Humidity Up to 98%
Storage Humidity 5% to 95% - non-condensing
Storage Temperature -40°C to +80°C
Flammability Rating UL 94-HB, ECE-R118.02 Certified cables
Impact Resistance IK08
Environmental & Product Safety Compliance Complies with CE, EN, CSA, RoHS and
IEC standards, E-mark certified

Comparison With Other XPOLs


XPOL-6-10M XPOL-2 XPOL-2-5G
Gain (Max) 11dBi 9dBi 11dBi
Supported Network WiFi, 2G, 3G, 4G WiFi, 2G, 3G, 4G WiFi, 2G, 3G, 4G, 5G
Supported
Frequency Bands
1710 - 2700 MHz 698 - 960 MHz
1710 - 2170 MHz
2300 - 2400 MHz
2500 - 2700 MHz
698-960 MHz
1710-2700 MHz
3400-3800 MHz
3400 - 4200 MHz
Supported
Network/Frequency (WiFi)
WiFi 2.4GHz WiFi 2.4GHz WiFi 2.4GHz
Supported
Network/Frequency (TDD LTE)
In MHz
Band 40 (230 - 2400)
Band 41 (2496 - 2690)
Band 38 (2570 - 2620)
Band 40 (2300 - 2400)
Band 41 (2496 - 2690)
Band 44 (703 - 803)
Band 40 (2300 - 2400)
Band 41 (2496 - 2690)
Band 44 (703 - 803)

What’s in the Box

Product Box’s Content Includes:

  • Antenna: Poynting A-XPOL-0002-V3
  • Mounting Bracket: Z-shaped mounting bracket

You can watch here to see what the XPOL-2-5G looks like.

Images and Illustrations

Performance Plots

Image: XPOL-2-V3-5G Antenna Performace Plots - Gain
XPOL-2-V3-5G Antenna Performance Plots - Gain
Image: Antenna Performance Plots - VSWR
XPOL-2-V3-5G Antenna Performance Plots - VSWR

Mounting Options:

Image: Showing Mounting Options for this 4G/5G antenna
XPOL-2-V3-5G Antenna Mounting Options (Pole or Wall Mounted)

Ordering Information

SKU A-XPOL-0002-V3-01 A-XPOL-0002-V3-02 A-XPOL-0002-V3-03
EAN 6009880915750 6009710920107 6009710920121
HS Code #85291069 #85291069 #85291069
Packaged Weight 1.98kg 1.86kg 2.3kg
Packaged Dimensions 375 x 267 x 98 mm 375 x 267 x 98 mm 375 x 267 x 98 mm
Master Box QTY 10 10 10
Master Box Weight 22.7kg 19kg 24.07kg
Master Box Dimensions 550 x 390 x 500mm 550 x 390 x 500mm 550 x 390 x 500mm

Product Option to Choose From (Antenna Variants)

Please take note, that you need to choose from one of the options below when adding this antenna to your shopping cart.

Option 1: 5m coax with SMA (Male):

  • Cable length: 5m ±5%
  • Coax cable type: Twin HDF-195
  • Connector type: 2 x SMA (Male), With finger grips for easier connection
  • Commercial Name: XPOL-2-V3-5G
  • Order Product Code: A-XPOL-0002-V3-01
  • EAN Number: 6009880915750

Option 2: 10m coax with SMA (Male):

  • Cable length: 10m ±5%
  • Coax cable type: Twin HDF-195
  • Connector type: 2 x SMA (Male), With finger grips for easier connection
  • Commercial name: XPOL-2-V3-5G
  • Order product code: A-XPOL-0002-V3-03
  • EAN number: 6009710920121

Option 3: Bulkhead N-Type (Female):

  • Cable Length: NA
  • Coax Cable Type: NA
  • Connector Type: Bulkhead N-Type (Female)

NOTE: This variant doesn’t come with cables, so you need to provide your own, or buy a pair of Poynting CAB-49 cable.

How to Buy the XPOL-2-5G

To buy this Wifi/4G/5G Outdoor Panel Antenna, simply click on the “add to cart” button and go through the secured checkout process. You can use any Credit Card supported by Stripe Payment Gateway.

You can also order via phone call, just dial +353 222 3440.

You could also drop by and buy from our physical store located Novatel Communications, Main Street, Buttevant, Co. Cork P51 K066

We ship nationwide and overseas.


If you’re looking for the older XPOL-2 model, then click on this link.

If you need an external outdoor router enclousure plus XPOL-2-5G antenna in one, then get the EPNT-2.
