Teltonika RUT200: Dual-WAN Auto Failover Capable 4G LTE Industrial Cellular Router
Available to Order
- Stock: Delivery Lead Time: 5-7 Days
- Brand: Teltonika
- Model: RUT200
- Weight: 389.00g
- Dimensions: 74.00mm x 83.00mm x 25.00mm
- MPN: RUT200
Highly Recommended Addons
Looking for a reliable and high-performance mobile router that can keep you connected and productive while on the go? Look no further than the Teltonika RUT200!
With its advanced features and cutting-edge technology, the Teltonika RUT200 is the perfect solution for anyone who needs fast and reliable mobile data connectivity. Whether you’re traveling for work, going on a road trip, or just need to stay connected while on the move, this powerful router has you covered.
Some of the key features of this 4G router include high-speed mobile data connectivity, advanced security features, and an easy setup process that makes it simple to get started right away. With its built-in SIM card slot, you can easily connect to your mobile network provider and start enjoying fast and reliable data speeds in no time.
But the benefits of using the RUT200 don’t stop there. By reducing your data costs and maximizing your efficiency, this powerful router can help you stay connected and productive no matter where you are. And with its rugged design and reliable performance, you can rest assured that you’ll always be able to stay connected and get things done.
Don’t just take our word for it - here’s what some of our satisfied customers have to say about the Teltonika RUT200:
“I’ve been using the Teltonika RUT200 for several months now, and I couldn’t be happier with its performance. It’s fast, reliable, and easy to use, and it’s helped me stay connected and productive while on the go.”
“The Teltonika RUT200 is a game-changer for anyone who needs reliable mobile data connectivity. It’s easy to set up, works flawlessly, and has saved me a ton of money on data costs.”
So why wait? If you’re looking for a powerful and reliable mobile router that can help you stay connected and productive no matter where you are, the Teltonika RUT200 is a perfect choice. So why not buy now and enjoy reliable mobile connectivity wherever you go!
RUT200 Technical Specifications
| MOBILE | |
|---|---|
| Mobile Module |
4G (LTE) – Cat 4 up to 150 Mbps 3G – Up to 42 Mbps, 2G – Up to 236.8 Kbps |
| Status | Signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, Bytes sent/received, connected band, IMSI, ICCID |
| SMS | SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP |
| USSD | Supports sending and reading Unstructured Supplementary Service Data messages |
| Black/White list | Operator black/white list |
| Multiple PDN | Possibility to use different PDNs for multiple network access and services |
| Band Management | Band lock, Used band status display |
| APN | Auto APN |
| Bridge | Direct connection (bridge) between mobile ISP and device on LAN |
| Passthrough | Router assigns its mobile WAN IP address to another device on LAN |
| WIRELESS | |
| Wireless Mode | IEEE 802.11b/g/n, Access Point (AP), Station (STA) |
| WiFi Security | WPA2-Enterprise - PEAP, WPA2-PSK, WEP, WPA-EAP, WPA-PSK; AES-CCMP, TKIP, Auto Cipher modes, client separation |
| SSID/ESSID | SSID stealth mode and access control based on MAC address |
| WiFi Users | Up to 50 simultaneous connections |
| Wireless Hotspot | Captive portal (Wi-Fi Hotspot), internal/external Radius server, built-in customizable landing page |
| ETHERNET | |
| WAN | 1 x WAN port 10/100 Mbps, compliance IEEE 802.3, and IEEE 802.3u standards, supports auto MDI/MDIX |
| LAN | 1 x LAN port, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX |
| NETWORK | |
| Routing | Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, NHRP) |
| Network Protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL) |
| VoIP Passthrough Support | H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
| Connection Monitoring | Ping Reboot, Wget Reboot, Periodic Reboot, LCP, and ICMP for link inspection |
| Firewall | Port forward, traffic rules, custom rules |
| DHCP | Static and dynamic IP allocation, DHCP Relay, Relayd |
| QoS / Smart Queue Management (SQM) | Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e |
| DDNS | Supported >25 DDNS service providers, others can be configured manually |
| Network Backup | WiFi WAN, Mobile, VRRP, and Wired options, each of which can be used as an automatic Failover |
| Load Balancing | Balance Internet traffic over multiple WAN connections |
| Hotspot | Internal/external Radius server, captive portal, built-in customizable landing page |
| SSHFS | With SSHFS it allows the possibility to mount remote file systems via SSH protocol |
| SECURITY | |
| Authentication | Pre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & Login attempts block |
| Firewall | Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T |
| Attack Prevention | DDoS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) |
| VLAN | Port and tag-based VLAN separation |
| Mobile Quota Control | Custom data limits for SIM card |
| WEB Filter | Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only |
| Access Control | Flexible access control of TCP, UDP, ICMP packets, MAC address filter |
| VPN | |
| OpenVPN | Multiple OpenVPN clients and a server can run simultaneously, and 27 encryption methods |
| OpenVPN Encryption | DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192, AES-192-CFB8 192, AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192, AES-256-GCM 256, AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256, AES-256-OFB 256, AES-256-CBC 256 |
| IPsec | IKEv1, IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192, AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12, AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16) |
| GRE | GRE tunnel, GRE tunnel over IPsec support |
| PPTP, L2TP | Client/Server instances can run simultaneously, L2TPv3, and L2TP over IPsec support |
| Stunnel | Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code |
| DMVPN | A DMVPN is a method of building scalable IPsec VPNs |
| SSTP | SSTP client instance support |
| ZeroTier | ZeroTier VPN client support |
| WireGuard | Wireguard VPN client and server support |
| Tinc | Tinc offers encryption, authentication, and compression in its tunnels. Client and server support. |
| MODBUS TCP SLAVE | |
| ID Range | Respond to one ID in the range [1;255] or any |
| Allow Remote Access | Allow access through WAN |
| Custom Registers | MODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Slave functionality |
| MODBUS TCP MASTER | |
| Supported Functions | 01, 02, 03, 04, 05, 06, 15, 16 |
| Supported Data Formats | 8 bit: INT, UINT; 16 bit: INT, UINT (MSB or LSB first); 32 bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC) |
| MODBUS DATA TO SERVER | |
| Protocol | HTTP(S), MQTT, Azure MQTT |
| MQTT GATEWAY | |
| MQTT Gateway | Allows sending commands and receiving data from MODBUS Master through MQTT broker |
| DNP3 | |
| Supported Modes | TCP Master, DNP3 Outstation |
| MONITORING & MANAGEMENT | |
| WEB UI | HTTP/HTTPS, status, configuration, FW update, CLI, troubleshooting, event log, system log, kernel log |
| FOTA | Firmware update from server, automatic notification |
| SSH | SSH (v1, v2) |
| SMS | SMS status, SMS configuration, send/read SMS via HTTP POST/GET |
| Call | Reboot, Status, Mobile data on/off, Output on/off, answer/hang-up with a timer, WiFi on/off |
| TR-069 | OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem |
| MQTT | MQTT Broker, MQTT publisher |
| SNMP | SNMP (v1, v2, v3), SNMP Trap |
| JSON-RPC | Management API over HTTP/HTTPS |
| MODBUS | MODBUS TCP status/control |
| RMS | Teltonika Remote Management System (RMS) |
| IoT PLATFORMS | |
| Cloud of Things | Allows monitoring of Device data, Mobile data, Network info, Availability |
| ThingWorx | Allows monitoring of WAN Type, WAN IP, Mobile Operator Name, Mobile Signal Strength, Mobile Network Type |
| Cumulocity | Allows monitoring of Device Model, Revision and Serial Number, WAN Type and IP, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength |
| Azure IoT Hub | Can send device IP, Number of bytes sent/received, Temperature, PIN count to Azure IoT Hub server, Mobile connection state, Network link state, IMEI, ICCID, Model, Manufacturer, Serial, Revision, IMSI, SIM State, PIN state, GSM signal, WCDMA RSCP, WCDMA EC/IO, LTE RSRP, LTE SINR, LTE RSRQ, CELL ID, Operator, Operator number, Connection type |
| SYSTEM CHARACTERISTICS | |
| CPU | Mediatek MIPS 24Kc 580 MHz |
| RAM | 128 MB, DDR2 |
| FLASH Storage | 16 MB, SPI Flash |
| FIRMWARE / CONFIGURATION | |
| WEB UI | Update FW from a file, check FW on the server, configuration profiles, configuration backup |
| FOTA | Update FW |
| RMS | Update FW/configuration for multiple devices at once |
| Keep Settings | Update FW without losing the current configuration |
| FIRMWARE CUSTOMIZATION | |
| Operating System | RutOS (OpenWrt-based Linux OS) |
| Supported Languages | Busybox shell, Lua, C, C++ |
| Development Tools | SDK package with build environment provided |
| INPUT / OUTPUT | |
| Input | 1 x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high |
| Output | 1 x Digital Output, Open collector output, max output 30 V, 300 mA |
| Events | Email, RMS, SMS |
| I/O juggler | Allows to set certain I/O conditions to initiate an event |
| POWER | |
| Connector | 4-pin industrial DC power socket |
| Input voltage range | 9 – 30 VDC, reverse polarity protection; surge protection >31 VDC 10us max |
| PoE (passive) | Passive PoE over spare pairs. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, LAN1 Port, 9 - 50 VDC |
| Power Consumption | < 6.5 W Max |
| PHYSICAL INTERFACES | |
| Ethernet | 2 x RJ45 ports, 10/100 Mbps |
| I/O | 1 x Digital Input, 1 x Digital Output on 4-pin power connector |
| Status LEDs | 3 x Connection type status LEDs, 5 x Connection strength LEDs, 2 x LAN status LEDs, 1 x Power LED |
| SIM | 1 x SIM slot (Mini-SIM – 2FF), 1.8 V/3 V, external SIM holder |
| Power | 1 x 4-pin power connector |
| Antennas | 2 x SMA for LTE, 1 x RP-SMA for WiFi antenna connectors |
| Reset | Reboot/User default reset/Factory reset button |
| PHYSICAL SPECIFICATION | |
| Casing Material | Aluminum housing, plastic panels |
| Dimensions (W x H x D) | 83 x 25 x 74 mm |
| Weight | 125 g |
| Mounting Options | Bottom and sideways DIN rail mounting slots |
| OPERATING ENVIRONMENT | |
| Operating Temperature | -40 °C to 75 °C |
| Operating Humidity | 10% to 90% non-condensing |
| Ingress Protection Rating | IP30 |
| REGULATORY & TYPE APPROVALS | |
| Regulatory | CB |
| SAFETY | |
| Standards | IEC 62368-1:2018 (CB Scheme) |
How do I configure Teltonika RUT200?
The web interface (WebUI), a graphical user interface that enables you to access and change the router’s settings via a web browser, can be used to configure Teltonika RUT200. Connect your device to the router’s LAN network and type its IP address (by default: 192.168.1.1) into the address bar of your browser to access the WebUI. To log in, you must enter the username and password (which is admin/admin01 by default). Using the Setup Wizard after logging in will let you change some of the most important device settings, including time, LAN, WAN, Wi-Fi, and RMS.
