TP-Link Archer MR200 4G LTE Dual-band Modem Plus Router
Available to Order
- Stock: Delivery Lead Time: 5-7 Days
- Brand: TP-Link
- Model: Archer MR200
The Archer MR200 3G/4G LTE router will let you share your Internet connection simultaneously, with up to 64 wireless devices like; smartphones, laptop, tablets and desktop computers via ethernet ports. It lets you enjoy a download speed of up to 150Mbps. You can create a dual-band network with this device, and run a simultaneous dual-band Wi-Fi networks, with a maximum speeds of up to 300 Mbps on the 2.4GHz band and 433 Mbps on the 5GHz band. It requires no further configuration once you turn it on, just pop in a compatible SIM card and start enjoying a speedy wireless connection.
Similar Products: Tenda 4G680 V2.0, Teltonika RUT240
MR200 VS MR6400
Check the below table for a quick comparison guide between the two LTE Routers.
|
|
MR200 | MR6400 |
|---|---|---|
| LTE Maximum Speed | 150Mbps | 150Mbps |
| Dual-band | Yes | No |
| Data Rate at 2.4GHz | 300Mbps | 300Mbps |
| Data Rate at 5GHz | 433Mbps | N/A |
| VPN Pass-through |
PPTP VPN IPSec VPN OpenVPN |
N/A |
| VPN |
PPTP VPN IPSec VPN OpenVPN |
PPTP VPN IPSec VPN OpenVPN |
| Detachable Antenna | Yes | Yes |
Archer MR200 Features
Great Coverage and Dual Band Wi-Fi: The MR200 features a dual-band Wi-Fi network, with a simultaneous connection at maximum speeds of up to 300Mbps on the 2.4GHz band and 433Mbps on the 5GHz band.
No Configuration Required: So simple to set up, just install a compatible LTE SIM card from your favorite mobile operator, power it on, an voila! You have now a WiFi network with a wireless Internet connection via the 3G or 4G LTE network. You can now enjoy a fast and stable Wi-Fi connection.
Mobile Wi-Fi with Ease: The Archer MR200 can be used as a mobile Internet and can be useful in mobile applications like in Point-of-Sale systems, remote locations, and the Internet for RVs and cars. It lets you quickly establish a powerful wireless network whenever you need it and wherever you go.
Versatile WAN Connection: Thanks to its WAN/LAN port feature, the TP-Link Archer MR200 is able to support a wide variety of Internet connections. It lets you connect via cable, fiber, and DSL modems, so you don't run out of options in getting online.
Technical Specification
See below the data table for MR200's full technical specifications.
| HARDWARE FEATURES | |
|---|---|
| Interface |
3x 10/100Mbps LAN Ports 1x 10/100Mbps LAN/WAN Port 1x Micro-SIM Card Slot |
| Button |
WPS/Reset Button WiFi On/Off Button Power On/Off Button |
| External Power Supply | 12V/1A |
| Dimensions ( W x D x H ) | 7.95 x 5.55 x 1.32 in. (202 x 141 x 33.6 mm) |
| Antenna |
V4/V2/V1: 2 Detachable 4G LTE Antennas V3: 2 Internal 4G LTE Antennas |
| WIRELESS FEATURES | |
| Wireless Standards | IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
| Frequency Bands | 2.4GHz and 5GHz |
| Data Rate |
300Mbps at 2.4GHz 433Mbps at 5GHz |
| Reception Sensitivity |
5GHz: 11a 54M: -74dBm 11ac HT20: -67dBm 11ac HT40: -64dBm 11ac HT80 : -60dBm 11n HT20: -71dBm 11n HT40: -70dBm 2.4G: 11g 54M: -76dBm 11n HT20: -73dBm 11n HT40: -67dBm |
| Transmit Power | CE: <20dBm (2.4GHz), <23dBm (5GHz) |
| Wireless Functions | Enable/Disable Wireless Radio, WMM, Wireless Statistics |
| Wireless Security |
64/128-bit WEP WPA/WPA2 WPA-PSK/WPA2-PSK |
| Network Type |
4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800 MHz) TDD-LTE B38/B39/B40/B41 (2600/1900/2300/2500 MHz) 3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900 MHz) |
| SOFTWARE FEATURES | |
| Quality of Service | Bandwidth Control |
| Operating Modes | 3G/4G Router / Wireless Router |
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) |
| Management | Access Control, Local Management, Remote Management, Schedule Reboot |
| DHCP | Server, Client, DHCP Client List, Address Reservation |
| Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS | DynDns, NO-IP |
| VPN Pass-Through | PPTP VPN, IPSec VPN, OpenVPN |
| VPN | PPTP VPN, IPSec VPN, OpenVPN |
| Access Control | Parental Control, Local Management Control |
| Firewall Security | DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding |
| Protocols | Supports IPv4 and IPv6 |
| Guest Network | 2.4GHz guest network x 1, 5GHz guest network x 1 |
| IPSec VPN | Supports up to 10 IPSec VPN Tunnels |
| OTHERS | |
| Certification | CE, RoHS |
| Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Package Contents
Box content includes the following items:
- Power Adapter
- RJ45 Ethernet Cable
- Quick Installation Guide
- The Archer MR200 (AC750 Wireless Dual-band 4G LTE Router)
System Requirements
- Micro SIM Card
- Internet Explorer 11, Firefox 12.0 or Later, Chrome 20.0 or Later
- Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux
- Safari 4.0 browsers or higher, or other Java-enabled browsers
