Teltonika RUT142: OPC UA Capable Ethernet Router with RS234 Port & Wi-Fi 4
- Stock: In Stock
- Brand: Teltonika Networks
- Model: RUT142
- Weight: 149.20g
- Dimensions: 68.60mm x 113.10mm x 25.00mm
- MPN: RUT142
Available Options
Imagine a world where your connection never falters – that’s the promise of Teltonika RUT142. A networking device equipped with the RS232 serial interface, two Ethernet ports, DIN rail, and an industrial 3-pin connector, and compact router that redefines secure, high-speed connectivity. Tailored for industrial manufacturers, remote project managers, and security-conscious businesses, the 142 is the answer to your network’s demands.
Key Features
Dive into the exceptional array of features that define our product, each meticulously designed to enhance your experience:
- Modbus, DLMS, DNP3, and OPC UA Capable
- Robust Design: Built to endure industrial demands.
- Wi-Fi 4 capabilities for wireless access and control.
- Dual 10/100 Mbps Ethernet ports for extensive connectivity.
- Integrated DIN rail and 3-pin power connector for easy installation.
- Enhanced Security: Protect sensitive data with advanced network segmentation.
- Streamlined Management: Effortless network control with remote management features.
- Seamless Connectivity: Maintain critical operations with uninterrupted internet access.
- Easy Installation: Quick setup in industrial environments with DIN rail and 3-pin connector.
Downloads
- Download Technical Specification (PDF)
- Quick Start Guide: EN (Web Page)
- User Manual: EN (Web Page)
- Download the Latest Firmware
How & Where to Buy?
Secure your network today with the RUT142.
To buy the Teltonika RUT142 OPC UA Industrial Router, you can drop by (requires prior appointment) our store located at Novatel Communications, Main St, Buttevant, Co. Cork, P51 K066, Ireland.
To order online, click on the Add to Cart button, and then go through the fast, easy, and secure checkout process. Payment is provided for your convenience via Authipay Payment Gateway. You can use any supported cards (MasterCard, Visa, etc).
How Will My Order Be Delivered?
Your order(s) will be shipped via express delivery and are typically delivered within 1-4 business days. Your order will be dispatched directly from our warehouse and you will be provided a piece of tracking information for your order after it is dispatched. If you have any questions about your order status, don’t hesitate to get in touch with us.
Connect to the world with Teltonika Networks Cellular Routers, the most reliable and secure devices for your network. Get them now at Novatel, your Teltonika Distributor in Ireland.
Get geeky with the RUT142 tech specs below.
WIRELESS | |
---|---|
Wireless mode | IEEE 802.11b/g/n, Access Point (AP), Station (STA) |
WiFi security | WPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK; AES-CCMP, TKIP, Auto Cipher modes, client separation |
SSID/ESSID | ESSID stealth mode |
Wi-Fi users | Up to 50 simultaneous connections |
Wireless Connectivity Features | Wireless mesh (802.11s), fast roaming (802.11r), Relayd, BSS transition management (802.11v), radio resource measurement (802.11k) |
Wireless MAC filter | Whitelist, blacklist |
Wireless QR Code Generator | Once scanned, a user will automatically enter your network without needing to input login information. |
ETHERNET | |
WAN | 1 x WAN port 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
LAN | 1 x LAN ports, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
NETWORK | |
Routing | Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing |
Network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL) |
VoIP Passthrough Support | H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
Connection Monitoring | Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection |
Firewall | Port forward, traffic rules, custom rules |
Firewall Status Page | View all your Firewall statistics, rules, and rule counters |
Ports Management | View device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so on |
Network Topology | Visual representation of your network, showing which devices are connected to which other device |
DHCP | Static and dynamic IP allocation, DHCP Relay |
QoS / Smart Queue Management (SQM) | Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e |
DDNS | Supported >25 service providers, others can be configured manually |
Network Backup | Wi-Fi WAN, VRRP, Wired options, each of which can be used as an automatic Failover |
Load Balancing | Balance Internet traffic over multiple WAN connections |
Hotspot | Captive portal (Hotspot), internal/external Radius server, SMS authorization, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customizable themes and option to upload and download customised hotspot themes |
SSHFS | Possibility to mount remote file system via SSH protocol |
SECURITY | |
Authentication | Pre-shared key, digital certificates, X.509 Certificates, TACACS+, RADIUS, IP & Login attempts block |
Firewall | Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T |
Attack Prevention | DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) |
VLAN | Port and tag-based VLAN separation |
WEB Filter | Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only |
Access Control | Flexible access control of SSH, Web interface, CLI and Telnet |
VPN | |
OpenVPN | Multiple clients and a server can run simultaneously, 27 encryption methods |
OpenVPN Encryption | DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192, AES-192-CFB8 192, AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192, AES-256-GCM 256, AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256, AES-256-OFB 256, AES-256-CBC 256 |
IPsec | IKEv1, IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192, AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12, AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16) |
GRE | GRE tunnel, GRE tunnel over IPsec support |
PPTP, L2TP | Client/Server instances can run simultaneously, L2TP v3, L2TP over IPsec support |
Stunnel | Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code |
DMVPN | DMVPN is method of building scalable IPsec VPNs |
SSTP | SSTP client instance support |
ZeroTier | ZeroTier VPN client support |
WireGuard | WireGuard VPN client and server support |
Tinc | Tinc offers encryption, authentication and compression in it's tunnels. Client and server support. |
OPC UA | |
Supported Modes | Client, Server |
Supported connection types | TCP |
MODBUS | |
Supported Modes | Server, Client |
Supported Connection Types | TCP, RTU (RS232) |
Custom Registers | MODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Client functionality |
Supported Data Formats | 8-bit: INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII |
DATA TO SERVER | |
Protocol | HTTP(S), MQTT, Azure MQTT |
Data To Server | Extract parameters from multiple sources and different protocols, and send them all to a single server |
MODBUS MQTT GATEWAY | |
MODBUS MQTT GATEWAY | Allows sending commands and receiving data from MODBUS Server through MQTT broker |
DNP3 | |
Supported modes | Station, Outstation |
Supported Connection | TCP, RTU (RS232) |
DLMS | |
DLMS Support | DLMS - standard protocol for utility meter data exchange |
Supported Modes | Client |
Supported Connection Types | TCP, RTU (RS232) |
API | |
Teltonika Networks Web API (beta) support | Expand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation |
MONITORING & MANAGEMENT | |
WEB UI | HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event log, system log, kernel log |
FOTA | Firmware update from server, automatic notification |
SSH | SSH (v1, v2) |
Receive email message status alerts of various services | |
TR-069 | OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem |
MQTT | MQTT Broker, MQTT publisher |
SNMP | SNMP (v1, v2, v3), SNMP Trap |
JSON-RPC | Management API over HTTP/HTTPS |
RMS | Teltonika Remote Management System (RMS) |
IOT PLATFORMS | |
Cloud of Things | Allows monitoring of: Device name, HW version, Serial number, FW version, WAN IP. Allows actions from the cloud: FW update, Reboot |
ThingWorx | Allows monitoring of: Device name, HW version, Serial number, FW version, WAN IP. Allows actions from the cloud: FW update, Reboot |
Azure IoT Hub | Allows monitoring of: Wan IP, Number of bytes send/received, Model, Manufacturer, Serial, Revision, FW version and collected data of industrial devices |
SYSTEM CHARACTERISTICS | |
CPU | Mediatek, 580 MHz, MIPS 24KEc |
RAM | 128 MB, DDR2 |
FLASH Storage | 16 MB serial NOR flash |
FIRMWARE / CONFIGURATION | |
WEB UI | Update FW from file, check FW on server, configuration profiles, configuration backup |
FOTA | Update FW |
RMS | Update FW/configuration for multiple devices at once |
Keep Settings | Update FW without losing current configuration |
FIRMWARE CUSTOMISATION | |
Operating System | RutOS (OpenWrt based Linux OS) |
Supported Languages | Busybox shell, Lua, C, C++ |
Development Tools | SDK package with build environment provided |
GPL Customization | You can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients’ needs. |
POWER | |
Connector | 3-pos plugable terminal block |
Input Voltage Range | 9-30 VDC, reverse polarity protection, surge protection >31 VDC 10us max |
PoE (passive) | Passive PoE over spare pairs. Possibility to power up through LAN1 port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 30 VDC |
Power consumption | Idle: < 1 W / Max: < 2 W |
PHYSICAL INTERFACES | |
Ethernet | 2 x RJ45 ports, 10/100 Mbps |
Status LEDs | 1 x WAN type LED, 1 x LAN type LED, 1 x Power LED |
Power | 1 x 3-pin power connector |
Antennas | 1 x RP-SMA for Wi-Fi |
RS232 | 1 x DB9 socket |
Reset | Reboot/User default reset/Factory reset button |
Other | 1 x Grounding Screw |
PHYSICAL SPECIFICATION | |
Casing Material | Aluminium housing |
Dimensions (W x H x D) | 113.10 x 25 x 68.6 mm |
Weight | 149.2 g |
Mounting Options | Integrated DIN rail bracket |
OPERATING ENVIRONMENT | |
Operating temperature | -40 °C to 75 °C |
Operating humidity | 10% to 90% non-condensing |
Ingress Protection Rating | IP30 |
REGULATORY & TYPE APPROVALS | |
Regulatory | CE/RED, UKCA, CB, RCM, FCC, IC, EAC, UCRF, WEEE |
