Poynting XPOL-16: Multi-band 8dBi GSM/3G/4G LTE Outdoor Directional Antenna

Poynting XPOL-16: Multi-band 8dBi GSM/3G/4G LTE Outdoor Directional Antenna
Poynting XPOL-16: Multi-band 8dBi GSM/3G/4G LTE Outdoor Directional Antenna
Poynting XPOL-16: Multi-band 8dBi GSM/3G/4G LTE Outdoor Directional Antenna

Available to Order

Currently not in stock, available to order. Take note of the Estimated Delivery Lead Time below for this specific item, before placing your order(s), so you'd know when to expect delivery. Contact us for order-related enquiries.

€265.00
Ex Tax: €215.45
  • Stock: Delivery Lead Time: 7-10 Days
  • Brand: Poynting
  • Model: XPOL-16
  • Weight: 2.38kg
  • EAN: 6009693810143
  • MPN: A-XPOL-0016

The XPOL-16 is a 3G, GSM, and a 4G LTE external antenna that you can use in boosting mobile signal for various frequency bands. This Antenna can work on a wide band of frequencies which includes; 450-470, 790-860, and 1710-2170 MHz. It has an 8dBi maximum gain across all bands from 450 - 1880 MHz. It's light-weight, easy to install and comes with two mounting options, that is, pole and wall mount options.

It supports full LTE band and features an ultra wideband, separately fed antenna element, enclosed in a single ruggedly designed single housing made of ABS. The antenna is well-equipped in providing client-side MiMo support for the networks of today and tomorrow.

It is ideal for any application using the GSM application (LTE/HSPA/3G/EDGE/GPRS) and serves as a cost-effective solution in improving signal reception, throughput and reliability.

Reference Image: Poynting XPOL-16 Antenna Features
Poynting XPOL-16 Features

Antenna Performance

Voltage Standing Wave Ratio (VSWR)

VSWR is a measure of how efficiently radio-frequency power is transmitted from a power source, through a transmission line, into a load. In an ideal system, 100% of the energy is transmitted which corresponds to a VSWR of 1:1. The XPOL-16 delivers superior performance across all bands with a VSWR of 2.5:1 or better.

Gain in dBi

8 dBi is the peak gain across all bands from 450 - 1880 MHz

  • Gain @ 450 - 470 MHz: 6.5 dBi
  • Gain @ 790 - 860 MHz: 8 dBi
  • Gain @ 1710 - 2170 MHz: 8 dBi

NOTE: Antenna gain is measured with polarisation aligned standard antenna

Key Features

  • Increased connectivity stability
  • Futureproof wideband LTE antenna
  • Weather and vandal-resistant enclosure
  • Backward compatible with 3G and 2G technologies
  • Improves mobile network subscriber's user experience
  • Two antennas in one enclosure for optimal LTE performance
  • Light Weight & Easy to Mount/Install (Wall or pole mountable)

Application Areas

  • Unstable connection
  • Urban and Rural Areas
  • Machine-to-machine (M2M)
  • Slow data transmission connection
  • Increase system transmission reliability
  • Poor data signal reception (indoor or outdoor)
  • LTE fringe areas (close to an LTE area, but just out of reach)
  • Network operator flexibility - as the antennas is wideband, a new antenna is not needed per network operator - works on most networks

Technical Specification

See the below table for XPOL-16's full technical specifications.

Electrical Specifications
Frequency Bands 450 - 470 MHz
790 - 860 MHz
1710 – 2170 MHz
Gain (Max) 8 dBi
VSWR <2.5:1
Feed Power Handling 10 W
Input impedance 50 Ohm (nominal)
Polarisation +45° and -45°
Port to Port Isolation >15dB
MIMO Decorrelation < 0.3
Cable Loss 0.3 dB/m @ 450 MHz
0.35dB/m @ 900 MHz
0.53dB/m @ 2000 MHz
DC Short Yes
Mechanical Specifications
Product Dimensions (L x W x D) 350x350x90mm
Packaged Dimensions 360x360x98mm
Weight 1.98 kg
Packaged Weight 2.38 kg
Radome Material ABS (Halogen Free)
Radome Colour Pantone - Cool Gray (1C)
RAL – 7047
Environmental Specifications
Wind Survival <120km/h
Temperature Range (Operating) -40°C to +70°C
Environmental Conditions Outdoor/Indoor
Operating Relative Humidity Up to 98%
Storage Humidity 5% to 95% - non condensing
Storage Temperature -40°C to +70°C
Certification Approvals and Standards
Flammability Rating UL 94-V0
EN 13823
Water Ingress Protection Ratio/Standard IP 65 (NEMA 4X)
Impact resistance IK 08
Salt Spray MIL-STD 810F/ASTM B117
Product Safety & Standards Complies with UL, CE, EN, CSA and IEC standards

Downloads

Product Box Contents

Box content includes the following:

  • Antenna: The Poynting A-XPOL-0016 Antenna
  • Mounting Bracket: 1 x Z-shaped mounting bracket suitable for wall or pole mount
  • Cable Length: 5m ±5%
  • Cable Type: Twin HDF 195
  • Connector: 2 x Gold Plated SMA (male). NOTE: The connector is factory mounted to the antenna.

Ordering Information

  • Commercial Name: XPOL-16
  • Order Product Code: A-XPOL-0016
  • EAN Number: 6009693810143
