TP-Link OC200 Omada Hardware Controller: Centralized Management of Up to 100 APs

TP-Link OC200 Omada Hardware Controller: Centralized Management of Up to 100 APs

Available to Order

Currently not in stock, available to order. Take note of the Estimated Delivery Lead Time below for this specific item, before placing your order(s), so you'd know when to expect delivery. Contact us for order-related enquiries.

Ex Tax: €77.24
  • Stock: Back Order
  • Brand: TP-Link
  • Model: OC200
  • Dimensions: 3.90in x 3.90in x 1.00in
  • MPN: OC200

Transform your network management, Unleash the Power of Centralized Network Management with the compact yet powerful TP-Link OC200!

The OC200 is a centralized hardware controller designed to configure, manage, and monitor Omada capable access points, switches, and routers effortlessly (it’s like Teltonika Networks’ RMS). With its robust design and advanced features, it simplifies network management for businesses of all sizes. It is ideal for IT administrators and business owners seeking a streamlined solution to complex network setups, the OC200 addresses the need for a reliable, secure, and easy-to-manage networking environment.

OC200 is a Hardware Contoller for Software Defined Networking Using TP-Link Compatible Units
OC200 is a Hardware Contoller for Software Defined Networking Using TP-Link Compatible Units

Key Features

Delve into the distinctive array of features that set the OC200 apart.

For the tech-savvy IT Administrator who craves control and efficiency, the TP-Link OC200 Hardware Controller is your command center. Here’s how it empowers you:

  • Unified Network Command: Command up to 100 Omada APs, 20 JetStream switches, and 10 routers from a single pane of glass.
  • Cloud-Enabled Oversight: With the Omada app or Web UI, you have the freedom to supervise and adjust your network from any location, at any time.
  • Local Management Mastery: Exercise ultimate control and ensure peak security with on-site management capabilities.
  • Premier Hardware Architecture: Equipped with a robust chipset, resilient metal housing, USB 2.0 for automatic backups, and dual Fast Ethernet ports.
  • Versatile Energy Options: Power up with the convenience of 802.3af/at PoE or Micro USB, ensuring adaptability in various setups.
  • Smart Network Surveillance: Utilize an intuitive dashboard for a clear view of network health and activity flow.
  • Instantaneous Topological Insight: Visualize and resolve network issues swiftly with a comprehensive network topology overview.
  • Streamlined Network Upkeep: Benefit from tools like a WiFi heatmap simulator and network reports for simplified, multi-site network management.

These features are not just bullet points; they’re your arsenal for a seamless network experience. ️

Technical Specification

Get geeky with the technical specs below.

Interface 2 × 10/100Mbps Ethernet Port
1 × USB 2.0 Port for configuration backup
1 × Micro USB Port for power
Power Supply 802.3af / 802.3atPoE or Micro USB (DC 5V/1A)
Dimensions 3.9 × 3.9 × 1.0inch / 100 × 98 × 25mm
Omada App Yes, Omada APP Compatible
Centralized Management Up to 100 Omada access points, 20 JetStream switches, and 10 Omada routers, Up to 1,000 Clients (compared to OC300; 500 Omada access points, 100 JetStream switches, and 100 Omada routers, up to 15,000 clients)
Note: Please refer to this link, to find all the device models supported by OC200
Cloud Access Yes
L3 Management Yes
Multi-site Management Yes
Management Features Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
Captive Portal Configuration
Certification CE, FCC, RoHS
System Requirements Microsoft® Windows®10, 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux
Environment Operating Temperature: 0–40°C (32–104 °F)
Storage Temperature: -40–70°C (-40–158 °F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing

How & Where to Buy?

Take the first step towards a smarter, more efficient network. Get your Omada Controller today!

To buy the TP-Link OC200 Omada Hardware Controller, you can drop by (requires prior appointment) our store located at Novatel Communications, Main St, Buttevant, Co. Cork, P51 K066, Ireland.

To order online, click on the Add to Cart button, and then go through the fast, easy, and secure checkout process. Payment is provided for your convenience via Authipay Payment Gateway. You can use any supported cards (MasterCard, Visa, etc).

How Will My Order Be Delivered?

Your order(s) will be shipped via express delivery and are typically delivered within 1-4 business days. Your order will be dispatched directly from our warehouse and you will be provided a piece of tracking information for your order after it is dispatched. If you have any questions about your order status, don’t hesitate to get in touch with us.

Discover the World of TP-Link: Your Gateway to Advanced Connectivity. Dive into our extensive range of innovative networking solutions and elevate your digital experience today!
