Poynting Swirl: GNSS / Wi-Fi & 5G/4G Antenna For Marine Applications
Available to Order
Wi-Fi, GNSS, and 5G/4G cross-polarised antenna for maritime and mobility applications. Unlock Unmatched Connectivity with the Poynting Swirl Series!
The Poynting Swir Series Cellular Antenna is a cutting-edge antenna solution designed to meet the demanding needs of maritime and mobility applications. Whether you’re navigating the high seas or on the move, the Swirl-4 ensures you stay connected with its robust and versatile features. This product is perfect for professionals and enthusiasts who require reliable, high-performance connectivity in challenging environments.
Key Features
Each feature of the Swirl Antenna System is meticulously designed to solve connectivity issues, enhance user experience, and provide reliable performance in any environment:
- Dual-Band GNSS Antenna: Accurate positioning with L1 and L5 constellations.
- Innovative Heat Sink Design: Ensures optimal performance by regulating temperature effectively.
- Dual-Band Wi-Fi Antennas: Enjoy seamless connectivity with 2.4 GHz and 5 to 7.2 GHz Wi-Fi bands.
- 4x Cross-Polarised Cellular Antennas: Covering frequencies from 617 to 6000 MHz, these antennas provide exceptional signal strength and stability.
- Compact and Durable Design: With dimensions of 382 mm in diameter and 127 mm in height, the Swirl Antenna Series by Poynting is built to withstand harsh conditions, boasting IP69K and IK08 ratings.
Benefits
Using the Poynting Swirl translates to numerous benefits:
- Enhanced Productivity: Reliable connectivity means smoother operations, whether you’re at sea or on the move.
- Cost Savings: By minimizing signal loss and reducing the need for additional equipment, the SWRL helps save on operational costs.
- Improved Efficiency: With its high-gain antennas, this cellular antenna model ensures faster data speeds and more reliable connections, reducing downtime and enhancing productivity.
Imagine a maritime crew seamlessly coordinating their tasks without connectivity issues, or a mobile team accessing critical data in real-time. The Swirl-4 makes these scenarios a reality.
What sets the Poynting Swirl apart from the competition?
These unique aspects make the Swirl a must-have for anyone needing reliable, high-performance connectivity:
- Versatility: Suitable for both maritime and mobility applications, the Swirl adapts to various environments.
- Exclusive Features: The innovative heat sink design and dual-band GNSS antenna are unique to the Poynting Swirl, ensuring superior performance.
- Seamless Integration: The Swirl (an antenna and router enclosure antenna system) can be transformed into a Customer Premises Equipment (CPE) device with the addition of the SWIRL-BASE, enhancing its functionality.
Downloads
Swirl Antenna Variants
|
Product Order Code (SKU) |
SWIRL-04-V1-01 | SWIRL-04-V1-02 | SWIRL-08-V1-01 | SWIRL-08-V1-02 |
| Integrated Base | No | Yes | No | Yes |
| Ports |
5G- Vertical Polarised (x2) 5G- Horizontal Polarised (x2) Wi-Fi- Vertical Polarised (x2) Wi-Fi- Horizontal Polarised (x2) GNSS (x 1) |
5G- Vertical Polarised (x2) 5G- Horizontal Polarised (x2) Wi-Fi- Vertical Polarised (x2) Wi-Fi- Horizontal Polarised (x2) GNSS (x 1) |
5G- Vertical Polarised (x4) 5G- Horizontal Polarised (x4) Wi-Fi- Vertical Polarised (x2) Wi-Fi- Horizontal Polarised (x2) GNSS (x1) |
5G- Vertical Polarised (x4) 5G- Horizontal Polarised (x4) Wi-Fi- Vertical Polarised (x2) Wi-Fi- Horizontal Polarised (x2) GNSS (x1) |
| SISO / MIMO |
4x4 MIMO- 5G 4x4 MIMO – Wi-Fi |
4x4 MIMO- 5G 4x4 MIMO – Wi-Fi |
8x8 MIMO- 5G 4x4 MIMO – Wi-Fi |
8x8 MIMO- 5G 4x4 MIMO – Wi-Fi |
| Frequency Bands | 617 - 6000 MHz | 617 - 6000 MHz | 617 - 6000 MHz | 617 - 6000 MHz |
| Polarisation | Vertical & Horizontal | Vertical & Horizontal | Vertical & Horizontal | Vertical & Horizontal |
| Peak Gain | 6dBi | 6dBi | 6dBi | 6dBi |
| Connector Type | 9 x SMA (male) | 9 x SMA (male) | 13 x SMA (male) | 13 x SMA (male) |
| Coax Cable Type | 9 x RG 316 with SMA (male) | 9 x RG 316 with SMA (male) | 13 x RG 316 with SMA (male) | 13 x RG 316 with SMA (male) |
| Coax Cable Length | 650 mm – 5G, Wi-Fi & GPS | 650 mm – 5G, Wi-Fi & GPS | 650 mm – 5G, Wi-Fi & GPS | 650 mm – 5G, Wi-Fi & GPS |
| Product Dimensions | Ø382 x 127 mm | Ø382 x 224 mm | Ø382 x 127 mm | Ø382 x 224 mm |
| Packaged Dimension | 440 x 430 x 190 mm | 520 x 420 x 270 mm | 440 x 430 x 190 mm | 520 x 420 x 270 mm |
| Weight | TBC | TBC | 2.83 Kg | 8.1 Kg |
| Packaged Weight | TBC | TBC | 4.5 Kg | 9.26 Kg |
| EAN | 6009710928578 | 6009710928578 | 6099710928639 | 6009710928875 |
How & Where to Buy?
Ready to experience the future of connectivity? Order your Poynting Swirl today and stay connected wherever you go.
To buy the Poynting Swirl (Cross-Polarised, Omni-Directional 5G/LTE, Multi MIMO Antenna Array), you can drop by our store located at Novatel Communications, Main St, Buttevant, Co. Cork, P51 K066, Ireland.
To order online, click on the Add to Cart button, and then go through the fast, easy, and secure checkout process. Payment is provided for your convenience via Authipay Payment Gateway. You can use any supported cards (MasterCard, Visa, etc).
How Will My Order Be Delivered?
Your order(s) will be shipped via express delivery and are typically delivered within 1-4 business days. Your order will be dispatched directly from our warehouse and you will be provided a piece of tracking information for your order after it is dispatched. If you have any questions about your order status, don’t hesitate to get in touch with us.
Looking for a land-based antenna system, check on the EPNT-4 Antenna with Router Enclosure.
