[EOL] TP-Link RE305 Dual-band 1200Gbps Wi-Fi Range Extender
![[EOL] TP-Link RE305 Dual-band 1200Gbps Wi-Fi Range Extender](https://www.novatel.ie/image/cache/catalog/products/tp-link-re305-wifi-range-extender_01-640x640w.jpg "[EOL] TP-Link RE305 Dual-band 1200Gbps Wi-Fi Range Extender")
![[EOL] TP-Link RE305 Dual-band 1200Gbps Wi-Fi Range Extender](https://www.novatel.ie/image/cache/catalog/products/tp-link-re305-wifi-range-extender_02-640x640w.jpg "[EOL] TP-Link RE305 Dual-band 1200Gbps Wi-Fi Range Extender")
![[EOL] TP-Link RE305 Dual-band 1200Gbps Wi-Fi Range Extender](https://www.novatel.ie/image/cache/catalog/products/tp-link-re305-wifi-range-extender_03-640x640w.jpg "[EOL] TP-Link RE305 Dual-band 1200Gbps Wi-Fi Range Extender")
Available to Order
- Stock: EOL
- Brand: TP-Link
- Model: RE305
- EAN: 6935364097981
- MPN: RE305
Stable 1.2Gbps Dual-band Wi-Fi Range Extender to bring dead zones to life. The RE305 can operate under an 867Mbps data rate under the 5GHz frequency band. Buy now!
The RE305 brings you a stable wireless networking experience, with up to 300Mbps data rate under the 2.4GHz frequency band, and a speed of up to 867Mbps in the 5GHz frequency band. Fast enough to stream HD, UHD, or even 8K video content inside your local area network.
You can easily extend your network either through ethernet or wireless means. So yeah, this extender can both act as a wifi access point and extender.
It comes with a similar feature to that of the TL-WA850RE, which has a LED signal light indicator, that helps you find the best possible location to place the extender in. A Blue LED light indicates a good Wi-Fi connection between the RE305 and your main router.
RE305 vs RE450
Here's a table for a quick comparison overview of the differences between the two devices.
|
|
RE305 | RE450 |
| Frequencies | 2.4GHz & 5GHz (11ac) | 2.4GHz & 5GHz (11ac) |
| Signal Rate |
5GHz:Up to 867Mbps 2.4GHz:Up to 300Mbps |
5GHz: Up to 1300Mbps 2.4GHz: Up to 450Mbps |
| Wireless Modes |
Range Extender/Access Point Wireless Statistic Concurrent Mode boosts both 2.4G/5G Wi-Fi band |
Range Extender |
| Wireless Functions |
LED Control Access Control Wireless Statistic Domain Login Function Concurrent Mode boosts both 2.4G/5G Wi-Fi band |
LED Control Access Control Wireless Statistic Domain Login Function Concurrent Mode boosts both 2.4G/5G WiFi band High Speed Mode for great speed for HD Gaming & video |
| Antenna | 2 x External | 3 x external |
| Interface | 1 x 10/100M Ethernet Port (RJ45) | 1 x 10/100/1000M Ethernet Port (RJ45) |
| Button | WPS Button, Reset Button | RE (Range Extender) Button, Reset Button, LED Button, Power Button |
Setup Overview
Expand your WiFi coverage with ease by connecting this network device to your primary router wirelessly, and start enjoying a high-speed WiFi connection once it is set up. Another way of connecting is through an Ethernet cable, just run a cable from your main router hosting your Internet to the RE305 Ethernet port.
3 Setup Methods
You can set up the device in 3 different methods:
- Method 1: Via the TP-Link Tether App (Search for TP-Link Tether in Google Play Store or AppStore)
- Method 2: Using a Desktop Browser like Chrome or Firefox
- Method 3: Using the WPS button
Technical Specifications
Read further below for the technical specifications of the RE305.
| Hardware Features | |
|---|---|
| Plug Type | EU, UK, US |
| Standards and Protocols | IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b |
| Interface | 1 x 10/100M Ethernet Port (RJ45) |
| Button | WPS Button, Reset Button |
| Power Consumption | 7.3W（max power consumption |
| Dimensions (W x D x H) | 3.1 x 3.0 x 3.0 inch (80 x 78 x 77mm) |
| Antenna | 2 x External |
| Wireless Features | |
| Frequency | 2.4GHz & 5GHz (11ac) |
| Signal Rate |
5GHz:Up to 867Mbps 2.4GHz:Up to 300Mpbs |
| Reception Sensitivity |
5GHz： 11a 6Mbps:-91dBm@10% PER 11a 54Mbps: -74dBm@10% PER 11ac HT20 mcs8: -68dBm@10% PER 11ac HT40 mcs9: -63dBm@10% PER 11ac HT80 mcs9: -59dBm@10% PER 2.4GHz 11g 54M: -79dBm@10% PER 11n HT20 mcs7: -77dBm@10% PER 11n HT40 mcs7: -74dBm@10% PER |
| Wireless Modes |
Range Extender/Access Point Wireless Statistic Concurrent Mode boosts both 2.4G/5G Wi-Fi band |
| Wireless Functions |
Wireless Statistic Concurrent Mode boosts both 2.4G/5G Wi-Fi band Access Control LED Control Domain Login Function |
| Wireless Security |
64/128-bit WEP WPA-PSK / WPA2-PSK |
| Transmission Power |
<17dBm(2.4GHz) <17dBm(5GHz) |
| Others | |
| Certification | CE, FCC, RoHS |
| Box Dimensions (W X D X H) | 6.15 x 4 x 3.7in. (156.5 x 101.5 x 95mm) |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux |
| Environment |
Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
What's in the Box
The package content includes:
- The RE305 AC1200 Wi-Fi Range Extender
- Quick Installation Guide
