Teltonika RUTM51: Dual-SIM 5G/4G Router with Dual-Band Wi-Fi
- Stock: In Stock
- Brand: Teltonika Networks
- Model: RUTM51
- Weight: 525.00g
- Dimensions: 95.00mm x 132.00mm x 44.20mm
- MPN: RUTM51
Available Options
Unlock the power of seamless connectivity with the Teltonika RUTM51 5G/4G Dual-SIM Router! This cutting-edge 5G router is designed to meet the demands of industrial users and tech enthusiasts alike, offering unparalleled performance and versatility at an unbeatable price.
The Teltonika RUTM51 is a robust and reliable 5G router that brings high-speed internet connectivity to your fingertips. Whether you’re managing complex industrial operations or seeking a powerful network solution for your home or office, the RUTM51 has you covered.
But wait! there’s more! This 5G router is Auto-failover/Auto-switch capable, allowing you to configure to auto switch SIMs on certain parameters such as, low mobile signal, or no data. Also WAN Bonding capable via 3rd-party software package.
Key Features
Each feature of the Teltonika RUTM51 is designed to solve specific challenges, from ensuring uninterrupted connectivity to enhancing network security and performance:
- 5G/4G Connectivity: Experience lightning-fast internet speeds with 5G and 4G support, ensuring you stay connected even in the most demanding environments.
- CAT12 Speed: devices can achieve maximum download speeds of up to 600 Mbps. Considered part of LTE Advanced Pro, which supports more frequency bands and carrier aggregation, enhancing overall performance and capacity.
- WiFi: Enjoy seamless wireless connectivity with advanced WiFi capabilities, perfect for both small and large-scale deployments.
- VLAN: Enhance network segmentation and security with VLAN support, allowing you to create isolated networks for different applications.
- VPN: Secure your data with robust VPN capabilities, providing encrypted connections for remote access and secure communications.
- WAN Bonding: Achieve unparalleled network reliability and speed with WAN bonding, supported via third-party software, combining multiple internet connections into one.
Benefits
Using the Teltonika RUTM51 offers numerous benefits:
- Improved Efficiency: With high-speed 5G connectivity, tasks that require large data transfers or real-time communication become faster and more efficient.
- Cost Savings: The budget-friendly price of the RUTM51 means you get top-tier performance without breaking the bank.
- Enhanced Productivity: Reliable internet connectivity ensures that your operations run smoothly, minimizing downtime and maximizing productivity.
- Security: Advanced VPN and VLAN features protect your network from unauthorized access and cyber threats.
Comparison
Performance Comparison
The RUTM51 offers slightly slower speeds compared to the RUTX50. Speed tests show that the RUTX50 performs better due to the slightly powerful module. If you want best of both worls, get the RUTC50 for speed and power, plus a possible 500Mbps WAN Bonded speed from multiple internet source (i.e. Starlnk, Fibre, 5G)
Pricing
The RUTM51 is cheaper than the RUTX50. As a result, it is expected that the RUTM51 will not perform at the same level as the RUTX50. While it supports 5G, its performance will be slightly lower.
When to Choose RUTM51
If speed is not your main concern but you require 5G connectivity, the RUTM51 is an excellent option. However, if speed is critical for your use case, it would be better to opt for the RUTX50 or RUTC50.
Future-Proofing for 4G Users
The RUTM51 is a great alternative for 4G users looking to future-proof their network setup. It offers better connectivity and higher network capacity than 4G, making it a good choice for those transitioning from 4G to 5G. The main advantage of this new 5G device is its affordability, particularly aimed at 4G customers, as 2G and 3G networks are being phased out and 5G represents the future.
Technical Specification Comparison
TECHNOLOGY | |||
---|---|---|---|
|
RUTM51 | RUTX50 | RUTC50 |
5G | Yes | Yes | Yes |
4G (LTE) | Cat 12 | Cat 20 | Cat 20 |
3G | Yes | Yes | Yes |
Wi-Fi | Dual-Band (b/g/n/ac) | Dual-Band (b/g/n/ac) | Dual Band, 2.4 GHz (b/g/n/ac/ax) |
Ethernet | 10/100/1000 | 10/100/1000 | 10/100/1000 |
SMS | Yes | Yes | Yes |
GNSS | N/A | Yes | Yes |
HARDWARE | |||
|
RUTM51 | RUTX50 | RUTC50 |
RAM | 256 MB | 256 MB | 512MB DDR3 |
Flash Memory | 256 MB | 256 MB | 16MB NOR, 512MB NAND |
Ethernet Ports | 5 | 5 | 5 |
Passive PoE In | Yes | Yes | Yes |
Inputs/Outputs | 2 | 2 | 2 |
Power LED | 1 | 1 | 1 |
USB | Yes | Yes | Yes |
I/O Connector | 4-pin | 4-pin | 4-pin |
Mobile Antenna | 4x SMA | 4x SMA | 4x SMA |
Wi-Fi Antenna | 2x RP-SMA | 2x RP-SMA | 3x RP-SMA |
SIM Card Slots | 2x 2FF | 2x 2FF | 2x 2FF |
Power Consumption | Idle: < 4 W, Max: < 18 W | Idle: < 4 W, Max: < 18 W | Idle: < 4.5 W, Max: < 13.5 W |
Dimensions (W x H x D) | 132 x 44.2 x 95.1 mm | 132 x 44.2 x 95.1 mm | 130.4 x 42.6 x 103.4 mm |
Housing Material | Anodized aluminum housing and panels | Anodized aluminum housing and panels | Anodized aluminum housing and panels |
CPU | 717 MHz | 717 MHz | 1.3 Ghz |
Power Socket | 4-pin | 4-pin | 4-pin |
Supply Voltage | 9 – 50 VDC | 9 – 50 VDC | 9 – 50 VDC |
Operating Temperature | -40 °C to 75 °C | -40 °C to 75 °C | -40 °C to 75 °C |
Mounting Options | DIN rail, wall mount, flat surface (all require additional kit) | DIN rail, wall mount, flat surface (all require additional kit) | DIN rail, wall mount, flat surface (all require additional kit) |
GPS Antenna | N/A | 1x SMA | 1x SMA |
SOFTWARE | |||
|
RUTM51 | RUTX50 | RUTC50 |
Operating system | RutOS | RutOS | RutOS |
Modbus TCP Client | Yes | Yes | Yes |
NTP client/NTP server | Yes | Yes | Yes |
Input events | Yes | Yes | Yes |
Wake on LAN (WOL) | Yes | Yes | Yes |
Manual Band Lock | Yes | Yes | Yes |
Modbus TCP Server | Yes | Yes | Yes |
MQTT Gateway | Yes | Yes | Yes |
USSD | Yes | Yes | Yes |
DNP3 Station | Yes | Yes | Yes |
DNP3 Outstation | Yes | Yes | Yes |
Modbus Gateway | Yes | Yes | Yes |
Samba shares | Yes | Yes | Yes |
Printer server | Yes | Yes | Yes |
USB to Serial | Yes | Yes | Yes |
SSTP | Yes | Yes | Yes |
Stunnel | Yes | Yes | Yes |
Management via SMS | Yes | Yes | Yes |
Bridge mode | Yes | Yes | Yes |
Manual operator selection | Yes | Yes | Yes |
Dynamic routing | Yes | Yes | Yes |
Hotspot | Yes | Yes | Yes |
Wireless Client | Yes | Yes | Yes |
Wireless AP | Yes | Yes | Yes |
Ping reboot | Yes | Yes | Yes |
Periodic reboot | Yes | Yes | Yes |
Real-time graphs | Yes | Yes | Yes |
WAN Failover | Yes | Yes | Yes |
Mobile Traffic Counter | Yes | Yes | Yes |
Connection status overview bar | Yes | Yes | Yes |
Configuration backup/restore | Yes | Yes | Yes |
VRRP | Yes | Yes | Yes |
Ipsec | Yes | Yes | Yes |
GRE Tunnel | Yes | Yes | Yes |
OpenVPN | Yes | Yes | Yes |
PPTP | Yes | Yes | Yes |
L2TP | Yes | Yes | Yes |
SNMP | Yes | Yes | Yes |
Send/receive SMS | Yes | Yes | Yes |
Status via SMS | Yes | Yes | Yes |
SMS reboot | Yes | Yes | Yes |
Web Filter | Yes | Yes | Yes |
Mobile Data Limit | Yes | Yes | Yes |
Configuration profiles | Yes | Yes | Yes |
Profiles scheduler | Yes | Yes | Yes |
Event logging | Yes | Yes | Yes |
QoS | Yes | Yes | Yes |
SIM switch | Yes | Yes | Yes |
FOTA (Firmware Over the Air) | Yes | Yes | Yes |
Event reporting (via Email/SMS) | Yes | Yes | Yes |
Speed test | Yes | Yes | Yes |
Disable Roaming | Yes | Yes | Yes |
SMS gateway | Yes | Yes | Yes |
OSPF | Yes | Yes | Yes |
Access control | Yes | Yes | Yes |
VLAN | Yes | Yes | Yes |
CLI | Yes | Yes | Yes |
Firewall | Yes | Yes | Yes |
Dynamic DNS | Yes | Yes | Yes |
RMS support | Yes | Yes | Yes |
DLMS Support | Yes | Yes | Yes |
Geofencing | N/A | Yes | Yes |
GPS data upload to AVL server | N/A | Yes | Yes |
NTRIP client | N/A | N/A | Yes |
CLASSIFICATION CODES
- HS Code: 851762
- HTS: 8517.62.00
VERSIONS
AVAILABLE VERSIONS |
|
||
---|---|---|---|
RUTM51 1***** EMEA1, APAC2, Latin America |
5G NR: n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n66, n77, n78 LTE-FDD: B1, B2, B3, B4, B5, B7, B8, B20, B28, B66 LTE-TDD: B38, B40, B41 3G: B1, B2, B5, B8 |
RUTM51 100000: Standard package with EU PSU RUTM51 100400: Standard package with AU PSU RUTM51 100500: Standard package with UK PSU RUTM51 100100: Mass packing code |
What’s In the Box
Standard Goodies Inside:
- The RUTM51 Router
- 18W PSU
- 4 x 5G Mobile antennas (swivel, SMA male)
- 2 x WiFi antennas (magnetic mount, RP-SMA male, 1.5 m cable)
- Ethernet cable (1.5 m)
- SIM Adapter kit
- QSG (Quick Start Guide)
- Packaging box, to keep or recycle
Downloads
- Download Technical Specification (PDF)
- Download the Latest Firmware
- Quick Start Guide: EN (Web Page)
- User Manual: EN (Web Page)
How & Where to Buy?
Ready to experience the power of the Teltonika RUTM51? Don’t wait—order now and take your connectivity to the next level!
To buy the Teltonika RUTM51 5G Router, you can drop by (requires prior appointment) our store located at Novatel Communications, Main St, Buttevant, Co. Cork, P51 K066, Ireland.
To order online, click on the Add to Cart button, and then go through the fast, easy, and secure checkout process. Payment is provided for your convenience via Authipay Payment Gateway. You can use any supported cards (MasterCard, Visa, etc).
How Will My Order Be Delivered?
Your order(s) will be shipped via express delivery and are typically delivered within 1-4 business days. Your order will be dispatched directly from our warehouse and you will be provided a piece of tracking information for your order after it is dispatched. If you have any questions about your order status, don’t hesitate to get in touch with us.
Connect to the world with Teltonika Networks Cellular Routers, the most reliable and secure devices for your network. Get them now at Novatel, your Teltonika Distributor in Ireland.
Get geeky with the Teltonika RUTM51 Full Technical Specifications below.
Technical Specifications
Mobile | |
---|---|
Mobile Module | 5G Sub-6GHz SA: 2 Gbps DL, 1 Gbps UL; NSA: 2.6 Gbps DL, 650 Mbps UL 4G (LTE) - Cat 12: 600 Mbps DL, Cat 13: 150 Mbps UL 3G - 42.2 Mbps DL, 11 Mbps UL |
3GPP Release | Release 15 |
SIM Switch | 2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection |
Status | IMSI, ICCID, Operator, Operator State, Data Connection State, Network Type, CA Indicator, Bandwidth, Connected Band, Signal Strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, Cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC |
SMS | SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP |
USSD | Supports sending and reading Unstructured Supplementary Service Data messages |
Black/White List | Operator black/white list (by country or separate operators) |
Band Management | Band lock, Used band status display |
SIM Idle Protection Service | When working with devices with two SIM slots, the one not currently in use will remain idle until the device switches to it, meaning that no data is used on the card until then |
SIM PIN Code Management | SIM PIN code management enables setting, changing, or disabling the SIM card's PIN |
APN | Auto APN |
Bridge | Direct connection (bridge) between mobile ISP and device on LAN |
Passthrough | Router assigns its mobile WAN IP address to another device on LAN |
Wireless | |
Wireless Mode | 802.11b/g/n/ac Wave 2 (Wi-Fi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO), 802.11r fast transition, Access Point (AP), Station (STA) |
Wi-Fi Security | WPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP OWE: AES-CCMP, TKIP, Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates, disable auto-reconnect, 802.11w Protected Management Frames (PMF) |
SSID/ESSID | ESSID stealth mode |
Wi-Fi Users | Up to 150 simultaneous connections |
Wireless Connectivity Features | Wireless Mesh (802.11s), Fast Roaming (802.11r), Relayd, BSS transition management (802.11v), radio resource measurement (802.11k) |
Wireless MAC Filter | Whitelist, Blacklis |
Wireless QR Code Generator | Once scanned, a user will automatically enter your network without needing to input login information. |
Ethernet | |
WAN | 1 x WAN port 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
LAN | 4 x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
Network | |
Routing | Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing |
Network Protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN |
VoIP Passthrough Support | H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
Connection Monitoring | Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection |
Firewall | Port forward, traffic rules, custom rules, TTL target customisation |
Firewall Status Page | View all your Firewall statistics, rules, and rule counters |
Ports Management | View device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so on |
Network Topology | Visual representation of your network, showing which devices are connected to which other devices |
DHCP | Static and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcards |
QoS / Smart Queue Management (SQM) | Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e |
DDNS | Supported >25 service providers, others can be configured manually |
DNS over HTTPS | DNS over HTTPS proxy enables secure DNS resolution by routing DNS queries over HTTPS |
Network Backup | Wi-Fi WAN, Mobile, VRRP, Wired options, each of which can be used as an automatic Failover |
Load Balancing | Balance Internet traffic over multiple WAN connections |
Hotspot | Captive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorisation, SSO authentication, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customisable themes and optionality to upload and download customised hotspot themes |
SSHFS | Possibility to mount remote file system via SSH protocol |
VRF Support | Initial virtual routing and forwarding (VRF) support |
Traffic Management | Real-time monitoring, wireless signal charts, traffic usage history |
Security | |
Authentication | Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal and External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator |
Firewall | Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T |
Attack Prevention | DDoS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) |
VLAN | Port and tag-based VLAN separation |
Mobile Quota Control | Mobile data limit, customizable period, start time, warning limit, phone number |
WEB Filter | Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only |
Access Control | Flexible access control of SSH, Web interface, CLI and Telnet |
SSL Certificate Generation | Let's Encrypt Support |
802.1x | Port-based network access control client |
VPN | |
OpenVPN | Multiple clients and a server can run simultaneously, 27 encryption methods |
OpenVPN Encryption | DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192, AES-192-CFB8 192, AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192, AES-256-GCM 256, AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256, AES-256-OFB 256, AES-256-CBC 256 |
IPsec | XFRM, IKEv1, IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192, AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12, AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16) |
GRE | GRE tunnel, GRE tunnel over IPsec support |
PPTP, L2TP | Client/Server instances can run simultaneously, L2TPv3, L2TP over IPsec support |
Stunnel | Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code |
DMVPN | Method of building scalable IPsec VPNs, Phase 2 and Phase 3 and Dual Hub support |
SSTP | SSTP client instance support |
ZeroTier | ZeroTier VPN client support |
WireGuard | WireGuard VPN client and server support |
Tinc | Tinc offers encryption, authentication and compression in it's tunnels. Client and server support. |
Tailscale | Tailscale offers speed, stability, and simplicity over traditional VPNs. Encrypted point-to-point connections using the open source WireGuard protocol |
OPC UA | |
Supported Modes | Client, Server |
Supported Connection Types | TCP |
MODBUS | |
Supported Modes | Server, Client |
Supported Connection Types | TCP, USB |
Custom Registers | Modbus TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Client functionality |
Supported Data Formats | 8-bit: INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII |
DATA TO SERVER | |
Protocol | HTTP(S), MQTT, Azure MQTT, Kinesis |
Data to Server | Extract parameters from multiple sources and different protocols, and send them all to a single server; Custom LUA scripting, allowing scripts to utilize the router's Data to server feature |
MQTT Gateway | |
Modbus MQTT Gateway | Allows sending commands and receiving data from MODBUS Server through MQTT broker |
DNP3 | |
Supported Modes | Station, Outstation |
Supported Connection | TCP, USB |
DLMS | |
DLMS Support | DLMS - standard protocol for utility meter data exchange |
Supported Modes | Client |
API | |
Teltonika Networks Web API (beta) support | Expand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation: https://developers.teltonika-networks.com |
Monitoring & Management | |
WEB UI | HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet status |
FOTA | Firmware update from server, automatic notification |
SSH | SSH (v1, v2) |
SMS | SMS status, SMS configuration, send/read SMS via HTTP POST/GET |
Call | Reboot, Status, Mobile data on/off, Output on/off, answer/hang-up with a timer, Wi-Fi on/off |
TR-069 | OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem |
MQTT | MQTT Broker, MQTT publisher |
SNMP | SNMP (v1, v2, v3), SNMP Trap, Brute force protection |
JSON-RPC | Management API over HTTP/HTTPS |
MODBUS | MODBUS TCP status/control |
RMS | Teltonika Remote Management System (RMS) |
IoT Platforms | |
ThingWorx | ThingWorx allows monitoring of: WAN Type, WAN IP, Mobile Operator Name, Mobile Signal Strength, Mobile Network Type |
Cumulocity - Cloud of Things | Allows monitoring of: Device Model, Revision and Serial Number, WAN Type and IP, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength. Has reboot and firmware upgrade actions |
Azure IoT Hub | Can be configured with Data to Server to send all the available parameters to the cloud. Has Direct method support which allows to execute RutOS API calls on the IoT Hub. Also has Plug and Play integration with Device Provisioning Service that allows zero-touch device provisioning to IoT Hubs |
System Characteristics | |
CPU | Mediatek, Dual-core, 880 MHz, MIPS1004KC |
RAM | 256 MB, DDR3 |
FLASH Storage | 16MB serial NOR flash, 256MB serial NAND flash |
Firmware / Configuration | |
WEB UI | Update FW from file, check FW on server, configuration profiles, configuration backup |
FOTA | Update FW |
RMS | Update FW/configuration for multiple devices at once |
Keep Settings | Update FW without losing current configuration |
Factory Settings Reset | A full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configuration |
FIRMWARE CUSTOMISATION | |
Operating System | RutOS (OpenWrt based Linux OS) |
Supported Languages | Busybox shell, Lua, C, C++ |
Development Tools | SDK package with build environment provided |
GPL Customization | You can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients' needs |
Package Manager | The Package Manager is a service used to install additional software on the device |
USB | |
Data rate | USB 2.0 |
Applications | Samba share, USB-to-serial |
External Devices | Possibility to connect external HDD, flash drive, additional modem, printer, USB-serial adapter |
Storage Formats | FAT, FAT32, exFAT, NTFS (read-only), ext2, ext3, ext4 |
Input / Output | |
Input | 1 x Configurable digital Input, 0 - 6 V detected as logic low, 8 - 50 V detected as logic high |
Output | 1 x Configurable digital Output, Open collector output, max output 50 V, 300 mA |
Events | Email, RMS, SMS |
I/O Juggler | Allows to set certain I/O conditions to initiate event |
Power | |
Connector | 4-pin industrial DC power socket |
Input Voltage Range | 9 – 50 VDC, reverse polarity protection, surge protection >51 VDC 10us max |
PoE (passive) | Possibility to power up through LAN1 port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 50 VDC |
Power Consumption | Idle: 5 W, Max: 18 W |
Physical Interfaces | |
Ethernet | 5 x RJ45 ports, 10/100/1000 Mbps |
I/O’s | 1 x Digital Input, 1 x Digital Output on 4-pin power connector |
Status LEDs | 3 x connection status LEDs, 3 x connection strength LEDs, 10 x Ethernet port status LEDs, 4 x WAN status LEDs, 1 x Power LED, 2 x 2.4G and 5G Wi-Fi LEDs |
SIM | 2 x SIM slots (Mini SIM – 2FF), 1.8 V/3 V |
Power | 1 x 4-pin power connector |
Antennas | 4 x SMA for Mobile, 2 x RP-SMA for Wi-Fi |
USB | 1 x USB A port for external devices |
Reset | Reboot/User default reset/Factory reset button |
Other | 1 x Grounding screw |
Physical Specification | |
Casing Material | Aluminium housing |
Dimensions (W x H x D) | 132 x 44.2 x 95.0 mm |
Weight | 525 g |
Mounting Options | DIN rail, wall mount, flat surface (all require additional kit) |
Operating Environment | |
Operating Temperature | -40 °C to 75 °C |
Operating Humidity | 10% to 90% non-condensing |
Ingress Protection Rating | IP30 |
Regulatory & Type Approvals | |
Regulatory & Type Approvals | CE, CB, UKCA, EAC, UCRF, RCM, WEEE |
Bulk Orders Welcome!
Are you looking to place a large order? We’ve got you covered! At Novatel, we are pleased to offer bulk order options for our valued customers. Whether you’re stocking up for a big event, taking on a large project for B2B clients, reselling, or needing a large quantity of our products, we’re here to help.
Why Choose Bulk Orders?
- Convenience: Get all the products you need in one go.
- Cost Savings: Enjoy significant discounts on bulk purchases.
- Priority Service: Receive dedicated support for your bulk order needs.
How to Place a Bulk Order:
- Contact Us: Reach out to our customer service team at +353 222 3440 or email us.
- Provide Details: Let us know the product(s) you’re interested in, the quantity, and any specific requirements.
- Get a Quote: We’ll provide you with a customized quote including bulk order discounts.
- Confirm Your Order: Once you’re happy with the quote, confirm your order and we’ll take care of the rest!
Need More Information?
If you have any questions or need further assistance, don’t hesitate to contact us. Our team is always ready to help you with your bulk order enquiries.
Thank you for choosing Novatel Communications Ltd. We look forward to serving you!
